1. Measure

 sample floor plan 800x600

Start with a tape measure, a pad and a pencil. You are almost there!

A. Room structure

Measure the ceiling height from floor to ceiling. Start with the first wall on the left and work your way right around the room (corner to corner).

B. Locating Windows

Indicate window and door location and sizes. Indicate all breaks in walls by measuring from the corner to the outside edge of the moulding. Indicate all appliance locations and width, height and depth.

C. Switches, Pipes etc.

Measure to centerline of plumbing, ducting and outlets. Finally, double check all dimensions.

563959 Download Cabinet Measurement Form
